ACCESS IN ACTION • FEBRUARY 2016

ACCESS in ACTION

Manitou’s secondary guarding system

– the Safe Man System – to maximise

operators’ safety, is compliant with the

EN 280 Standards and meets Australia’s

requirements for safety devices on aerial

work platforms.

A sensitive bar is fitted at the front of the

control panel without interfering with

the operator’s visibility on the control

panel. When the platform is active and

pressure is made on the sensitive bar

for more than three seconds, all of the

functions of the aerial platform become

inactive. An audible alarm is activated

and a blue beacon flashes and all

movements immediately stop. The boom

then automatically retracts. The operator

can free themselves by the use of a

bypass button which allows them to take

control and disengage. If the operator is

unconscious, it is possible to take control

Safe Man System secondary guarding system

Manitou has developed a dedicated solution for its aerial work platform range to

minimise crushing incidents which is now available on all Manitou aerial work

platforms as an option or as a kit.

of the machine from the controls at the

base of the access platform. This system,

which is becoming more requested,

ensures operator safety.

Manitou’s range of aerial work platforms

includes: Diesel platform range – with

working height up to 28ft; Articulated

platforms; Telescopic platforms; Electric

platforms – with working height up to

17m: Vertical work-platforms; Articulated

boom platforms; Bi-energy articulated

boom platforms; and Scissors.

Contact: 02 9517 3174 or visit website:

www.manitou-group.com

The SX-150 boom lift reaches its full

platform height of 46.33m (152ft) in

under three minutes. The boom offers

four programmable height settings of

45.72m (150ft), 41.15m (135ft), 36.58m

(120ft) and 30.48m (100ft) for rental

versatility and a 3.05m (10ft) horizontal

and vertical rotating jib allows for quick

local repositioning of the platform. With

a horizontal outreach of 24.38m (80ft),

this boom also offers 21.34m (70ft) of

outreach at 36.58m (120ft) of platform

height. The SX-150 boom lift provides

unrestricted range of motion with a lift

capacity of 340kg (750lbs) for a maximum

of two people. A standard 7.5kW on-

board generator powers tools. Weighing

22997kg (50,700lbs), with a tail swing

(axles extended) of 1.07m (3ft 6in) and

ground clearance of 0.38m (15in), the

boom lift is transportable on a standard

trailer; no over-size permits are required.

The boom uses an identical, field-proven

chassis design as employed on the

SX-180 and ZX-135 boom lifts. External

sensors and manifolds are protected

under steel covers that are easily removed

providing excellent service access. The

unit uses a Deutz Tier 4 interim engine.

The rotating jib worm drive reduces

backlash while increasing reliability and

offers 60 degrees of horizontal motion

for increased working area. The SX-150

boom lift contains hydraulic hard lines

where possible to increase durability

while a hydraulic filtration system

ensures cleanliness.

All manifolds offer easy wrench access

while a swing out engine tray provides

easy service or maintenance access. The

boom features easy to reach hydraulic

filters, with a drop-in return filter for easy

cleaning and replacement, as well as

bulkhead mount hydraulic lines, so hoses

can be removed and replaced in one

piece. The boom extend system features

a cylinder and wire rope cartridge for fast

service or replacement.

The Genie SX-150 boom lift is available in

Australia Q1 2016. Visit:

www.terex.com

Genie has rounded out its Super Boom product family with

the new Genie SX-150 telescopic boom lift.

Super boom line extended with new SX-150

The SX-150 boom lift reaches its

full platform height of 46.33m

(152ft) in under three minutes
